Intel Laminar RH1 Heatsink Cooler CPU Fan ARGB LED LGA1700
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Compatible Brand | Intel LGA1700 I9 |
| Socket Compatibility | LGA 1700 |
| Color | Multicolor |
| Material | Aluminum |
| MPN | Intel Laminar RH1 ARGB |
| Item Length | Up to 103mm x 103mm |
| To Fit | I9-13900 |
| Fan Light Color | Beige |
| Brand | Intel |
| Fan Diameter | 92 mm |
| Type | CPU Fan with Heatsink |
| Power Connection | 4-Pin |
| Unit Type | Unit |
| Voltage | 12 V |
| Maximum Fan Speed | 1000 - 3000 RPM |
| Item Width | Up to 103mm x 103mm |
Laminar RH1 ARGB LGA1700 CPU Fan This Intel® Laminar RH1 Cooler comes in the box with i9-14900, i9-14900F, i9-13900, i9-13900F and i9-12900, i9-12900F processors. These are not sold separately either to end-users or Intel® Partner Alliance members. The cooler has three-year limited warranty.Highlights of this coolerControllable ARGB Lighting2.6 BA Near-silent PerformanceLarger / Copper Heat ColumnIntel Validated CompatibilityIntel® Laminar RH1 Cooler Thermal Solution SpecificationsOverall HeightUp to 69mm (top of fan to bottom of heatsink)Overall SizeUp to 103mm x 103mmMassUp to 450gSound Power Level2.6 BA (1600 RPM, 40C inlet, 65W); 4.5 BA (max RPM)Sound Pressure Level16 dBA (1600 RPM, 40C inlet, 65W)TDP SupportUp to 65W (12th Gen Intel® Core™ Desktop Processors)Fan TypePWM controlled variable speed fanLEDsARGB LED light ring and white LED Intel logoConnector Types4-pin and 5V ARGBOperating Voltage13.2V max, 12.0V rated, 10.8V minCurrent (peak)Up to 450mAMax RPM (+/- 5%)Up to 3000 RPMMin RPM (+/- 20%)1000 RPMOperating Temp0 to 70COperating Humidity85% relative humidity @ 55CFan ProtectionLocked-rotor/polarity protectedSense Frequency2 pulses/Rev, 12V pull-up with 10KohmPWM Frequency25KHz +/- 5KHzPWM Pull-up Voltage5.25V maxPWM Duty Cycle Range0–100%
